Product Data

KSCdirect Part #: ZOE 98-0001
Description: M98 115V/1Ph/cCSAus/UL
MFG Part #: 98-0001
UPC: 053514029463
Supplier: Zoeller®
On Hand: In Stock - Available for immediate shipment.

Your Price: $349.50 / EA

QTY:
For shipping rates, add item to cart.
* Quantity discounts may be available. Call Kelly Supply at 800-918-8939.
Alternatively, you may e-mail info@kscdirect.com for service.

Details

Description

Zoeller® Effluent/Dewatering Submersible Pump, Automatic, Series: Flow-Mate M98, 73 gpm, 1-1/2 in Outlet, 23 ft Maximum Head, 1/2 hp, 115/230 V AC, 9.4 A, 60 Hz, 1 ph, 1725 rpm Motor, Non-Clogging Vortex Impeller, 130 deg F, Oil Fed Bearing, Cast Iron, 12-1/16 in H x 10-1/8 in W

Features:

  • Comes standard with the Zoeller LED Plug that allows you to check for power at a quick glance
  • Oil-filled motor and cast iron motor housing for optimal heat dissipation which prevents the pump from overheating
  • Automatic high flow sump pump with a time-tested, preset, built-in snap action switch that makes for easy installation
  • Corrosion resistant engineered plastic vortex impeller to allow free passage of solids which prevents clogging and lessens downtime
  • Stainless steel float guard that prevents material or debris from collecting on the float ensuring proper operation every time
  • Solid, buoyant, polypropylene float to eliminate the possibility of water infiltration allowing the float to remain buoyant and functional at all times
  • Powder-coated epoxy finish provides corrosion-resistance and extends the life of the pump in harsh environments
  • Stainless steel screws, switch arm, handle and hardware to prevent rust and corrosion over the life of the pump
  • 100 Percent Factory Tested - every pump is submerged in water and tested at the factory to ensure that it performs as expected when you receive it

Applications:

Dewatering (Sump), Enhanced Flow Step Systems, Low Pressure Pipe (LPP) and Septic Tank

Standards/Approval:

  • CSA/US Certified
  • SSPMA Certified
  • UL Listed

Attributes/Specifications

Amperage Rating 9.4 A
Bearing Type Oil Fed
Dimensions 12-1/16 in H x 10-1/8 in W
Flow Rate 73 gpm
Frequency Rating 60 Hz
Horsepower 1/2 hp
Impeller Type Non-Clogging Vortex
Material Cast Iron
Maximum Head 23 ft
Motor Speed 1725 rpm
Outlet Size 1-1/2 in
Phase 1
Series Flow-Mate M98
Temperature Rating 130 deg F
Type Automatic
Voltage Rating 115/230 V AC
Manufacturer Zoeller®
